| JTP/JTPB/2JTP/2JTPB Type Mining Winch Parameters | ||||||||||||||||||||
| Model | Reel | The maxmumstatic tension ofthe wire rope | Largest static tension difference of wire rope |
Maximum lifting height orlength of transport | Wire rope | Reduction ratio | Average hoistingspeed | Motor | Dimensiong Length×width×height | Theoretical Weight of host | ||||||||||
| Individual | Diameter | Width | Two drum central distance |
Manned | Load | Manned | Load | one layer of winding |
two layer of winding |
three layer of winding |
Largest diameter |
Sum of breaking pull force | Rotating speed | Maximum power | ||||||
| Unit | mm | kn | mm | mm | kn | m/s | r/min | kw | mm | kg | ||||||||||
| JTP-1*0.8P | 1 | 1000 | 800 | / | 15 | / | 179 | 360 | 543 | 12 | 97.5 | 31.5 | 1.6 | 985 | 37 | 3800*2380*1350 | 3430 | |||
| JTP-1.2*1P | 1 | 1200 | 1200 | / | 30 | 30 | 169 | 341 | 516 | 20 | 279 | 31.5 | 1.9 | 985 | 75 | 4458*2680*1450 | 9627 | |||
| JTP-1.2*1.2P | 1 | 1200 | 1200 | / | 15 | 21 | / | 205 | 413 | 625 | 20 | 279 | 31.5 | 1.9 | 967 | 55 | 4949*2680*2600 | 9711.2 | ||
| JTP-1.6*1.2P | 1 | 1600 | 1200 | / | 45 | 45 | 215 | 433 | 655 | 26 | 405 | 31.5 | 2.6 | 988 | 132 | 5224*2800*1925 | 14037 | |||
| JTP-1.6*1.5P | 1 | 1600 | 1500 | / | 45 | / | 269 | 542 | 819 | 26 | 405 | 31.5 | 2.5 | 975 | 110 | 5780*2800*1950 | 14200 | |||
| JTPB-1.2*1P | 1 | 1200 | 1000 | / | 30 | 30 | 169 | 341 | 516 | 20 | 279 | 31.5 | 1.9 | 967 | 75 | 4658*2680*1450 | 9940 | |||
| JTPB-1.2*1.2P | 1 | 1200 | 1200 | / | 30 | 30 | 205 | 413 | 625 | 20 | 279 | 31.5 | 1.9 | 967 | 75 | 4658*2680*1450 | 10421 | |||
| JTPB-1.6*1.2P | 1 | 1600 | 1200 | / | 45 | 45 | 215 | 433 | 655 | 26 | 405 | 31.5 | 2.6 | 975 | 132 | 5524*2800*1925 | 15195 | |||
| JTPB-1.6*1.5P | 1 | 1600 | 1500 | / | 45 | 45 | 269 | 542 | 819 | 26 | 405 | 31.5 | 2.6 | 975 | 132 | 5524*2800*1925 | 15678 | |||
| 2JTP-1.2*0.8P | 2 | 1200 | 800 | 874 | 30 | 20 | 137 | 275 | 415 | 20 | 279 | 31.5 | 1.9 | 987 | 55 | 5136*2680*1450 | 10386 | |||
| 2JTP-1.2*1P | 2 | 1200 | 1000 | 1070 | 15 | 21 | 15 | 21 | 169 | 341 | 516 | 20 | 279 | 31.5 | 1.9 | 967 | 55 | 5757*2680*1450 | 10027.2 | |
| 2JTP-1.6*0.9P | 2 | 1600 | 900 | 974 | 45 | 30 | 161 | 324 | 490 | 26 | 405 | 31.5 | 2.5 | 972 | 110 | 5905*2800*1925 | 16606.7 | |||
| 2JTP-1.6*1.2P | 2 | 1600 | 1200 | 1270 | 45 | 30 | 215 | 433 | 655 | 26 | 405 | 31.5 | 2.5 | 975 | 110 | 6768*2800*1950 | 15330 | |||
| 2JTPB-1.2*0.8P | 2 | 1600 | 800 | 874 | 30 | 20 | 137 | 275 | 415 | 20 | 279 | 31.5 | 1.9 | 967 | 55 | 5136*2680*1450 | 11520 | |||
| 2JTPB-1.6*0.9P | 2 | 1600 | 900 | 947 | 45 | 30 | 161 | 324 | 490 | 26 | 405 | 31.5 | 2.6 | 988 | 110 | 5905*2800*1925 | 14200 | |||
