DSJ retractable belt conveyor Technical Parameters
model	Transport capacity (t/h）	bandwidth（mm）	Belt speed（m/s）	Conveying length（m）	Motor power（kw）	Drum diameter（φmm）	Roller diameter（φmm）	inclination（°）
DSJ65/20/2×40	200	650	2	1000	2×40	500	89
DSJ65/30/2×40	300	650	2	800	2×40	630	89
DSJ65/20/2×55	200	650	2	1000	2×55	630	89
DSJ80/40/2×40	400	800	2	600	2×40	500	89
DSJ80/40/2×55	400	800	2	1000	2×55	630	89	0-10
DSJ80/45/2×75S	450	800	2	1000	2×75S	630	89	0-10
DSJ80/50/2×90	500	800	2.5	800	2×90	800	89
DSJ80/40/2×110	400	800	2.5	900	2×110	800	89
DSJ80/40/2×132	400	800	2.5	1200	2×132	800	89
DSJ80/50/2×132	500	800	2.5	1000	2×132	800	89
DSJ100/63/2×75	630	1000	2	1000	2×75	630	108	0-7
DSJ100/63/2×90	630	1000	2	1180	2×90	630	108	0-10
DSJ100/63/2×160	630	1000	2.5	1200	2×160	800	10	0-10
DSJ100/63/2×185	630	1000	2.5	1400	2×185	800	108
DSJ100/120/2×250	1200	1000	3.15	2050	2×250	800	133
