| flat-deck mine car Technical Parameters | ||||||||||
| model | Loading capacity（T） | gauge（mm） | Dimensions（mm） | Wheelbase（C) | Wheel diameter(D) | Traction high(H) | Traction（KN) | Deadweight | ||
| long | Width | high | ||||||||
| MPC2-6 | 2 | 600 | 2000 | 880 | 410 | 550 | 300 | 320 | 60 | ≤490 |
| MPC3-6 | 3 | 600 | 2400 | 1050 | 415 | 750 | 300 | 320 | 60 | ≤530 |
| MPC5-6 | 5 | 600 | 3450 | 1200 | 480 | 1100 | 350 | 320 | 60 | ≤900 |
| MPC5-9 | 5 | 900 | 3450 | 1320 | 480 | 1100 | 350 | 320 | 60 | ≤910 |
| MPC5-9A | 5 | 900 | 2100 | 1150 | 480 | 600 | 350 | 320 | 60 | ≤780 |
| MPC10-6 | 10 | 600 | 3350 | 1400 | 342 | 1000 | 220 | 270 | 60 | ≤880 |
| MPC13-6 | 13 | 600 | 3350 | 1400 | 342 | 1000 | 220 | 270 | 60 | ≤1015 |
| MPC15-9 | 15 | 900 | 3600 | 1300 | 406 | 1100 | 350 | 320 | 60 | ≤1320 |
| MPC18-6 | 18 | 600 | 3350 | 1400 | 346 | 1000 | 220 | 272 | 60 | ≤1132 |
| MPC20-6 | 20 | 600 | 3200 | 1380 | 450 | 1100 | 350 | 320 | 60 | ≤1600 |
| MPC26-6 | 26 | 600 | 2400 | 1460 | 390 | 1100 | 240 | 280 | 60 | ≤1133 |
| MPC30-9 | 30 | 900 | 4000 | 1350 | 418 | 1300 | 350 | 320 | 60 | ≤2020 |
| MPC35-9 | 35 | 900 | 3520 | 1350 | 410 | 1200 | 350 | 320 | 60 | ≤2286 |
| MPC40-9 | 40 | 900 | 3600 | 1300 | 406 | 1200 | 350 | 340 | 60 | ≤2047 |
| MPC50-6 | 50 | 600 | 3450 | 1400 | 438 | 1300 | 350 | 175 | 60 | ≤2450 |
| MPC50-9 | 50 | 900 | 3450 | 1400 | 438 | 1300 | 350 | 175 | 60 | ≤2550 |
| MPC55-6 | 55 | 600 | 3450 | 1400 | 438 | 1300 | 350 | 175 | 60 | ≤2522 |
| MPC55-9 | 55 | 900 | 3450 | 1400 | 438 | 1300 | 350 | 175 | 60 | ≤2630 |
