DTL Fixed Belt Conveyor Technical Parameters
model	Transport capacity（t/h）	bandwidth（mm）	Belt speed（m/s）	Conveying length	Motor power	Drum diameter	Roller diameter	inclination
DTL60/15/2×37	150	650	2	500	2×37	500	89
DTL60/30/2×55	300	650	2	500	2×55	500	89
DTL80/40/2×40	400	800	2	500	2×40	500	89	0-10
DTL80/40/2×55	400	800	2	700	2×55	500	89
DTL80/40/2×75	400	800	2	1000	2×75	630	89
DTL80/40/2×90	400	800	2	1200	2×90	630	89	0-15
DTL80/50/2×110S	500	800	2.5	1200	2×110	800	89
DTL80/50/2×132S	500	800	2.5	1400	2×132	800	89
DTL100/63/2×75S	630	1000	2	700	2×75	630	108	0-7
DTL100/63/2×90S	630	1000	2	1000	2×90	630	108	0-10
DTL100/63/2×110S	630	1000	2	1200	2×110	630	108
DTL100/63/2×132S	630	1000	2	1400	2×132	630	108	0-15
DTL100/63/2×160S	630	1000	2.5	1400	2×160	800	108
DTL100/63/2×220S	630	1000	2.5	1600	2×220	800	108
DTL100/63/2×250S	636	1000	2.5	1800	2×250	800	108
DTL120/80/2×280S	800	1200	3.15	1000	2×280	1000	133
DTL120/120/2×315S	1200	1200	3.15	1200	2×315	1000	133	0-14
DTL120/120/2×450S	1200	1200	3.15	1500	2×450	1000	133	0-18
