| NGW/NBD/ZZLplanetary reducer Technical Parameters | ||||||
| model | Speed Ratio | 20 | 25 | 28 | 31.5 | Suitable for winches |
| Speed | Input power p(kw) | |||||
| NGW112 | 1000 | 189 | 147 | 127 | 118 | JTP-1.2 2JTP-1.2 |
| NGW112 | 1000 | 257 | 212 | 187 | 167 | JTP-1.2、1.6 2JTP-1.6 |
| NGW112 | 750 | 331.3 | 224.6 | 185.7 | 185.7 | JTP-1.2 2JTP-1.6 |
| NGW112 | 1000 | 440.6 | 296.5 | 245.5 | 245.5 | JTP-1.6 2JTP-1.6 |
| NGW112 | 750 | 412.4 | 340.6 | 294.5 | 294.5 | JTP-1.6 JK-2.0 2JK-2.0 |
| NGW112 | 1000 | 548.3 | 453.2 | 391.9 | 391.9 | JTP-1.6 JK-2.0 2JK-2.0 |
| NGW112 | 750 | 663.2 | 508.2 | 425.1 | 425.1 | JK-2.0、2.5 2JK-2、2.5 |
| NGW112 | 1000 | 881.6 | 667.4 | 559.5 | 559.5 | JK-2.0、2.5 2JK-2、2.5 |
| NGW112 | 600 | 651.6 | 538.3 | 465.4 | 407.0 | JK-2.0、2.5 2JK-2.5、3.0 |
| NGW112 | 750 | 812.3 | 671.8 | 580.9 | 508.2 | JK-2.0、2.5 2JK-2.5、3.0 |
| NGW112 | 600 | 1057.9 | 844.9 | 700.0 | 665.8 | JK-2.5、3.0 2JK-2.5、3.0 |
| NGW112 | 750 | 1318.9 | 1044.3 | 866.3 | 831.1 | JK-2.5、3.0 2JK-2.5、3.0 |
| NGW112 | 600 | 1301.5 | 1033.1 | 893.4 | 802.0 | JK-3.0 2JK-3.0、3.5 |
| NGW112 | 750 | 1662.4 | 1288.4 | 1114.6 | 1001.0 | JK-3.0 2JK-3.0、3.5 |
| NGW112 | 600 | 2019.9 | 1603.2 | 1386.5 | 1211.1 | JK-3.5 2JK-3.0、3.5 |
| NGW112 | 750 | 2517.1 | 1999.1 | 1717.1 | 1511.5 | JK-3.5 2JK-3.0、3.5 |
| NGW112 | 600 | 2496.3 | 2064.3 | 1785.7 | 1565.4 | JK-3.5 2JK-3.5 |
| NGW112 | 750 | 3109.8 | 2573.2 | 2226.8 | 1953.0 | JK-3.5 2JK-3.5 |
