| DTC Belt Conveyor Technical Parameters | ||||||||
| model | Transport capacity（t/h） | bandwidth（mm） | Belt speed（m/s） | Conveying length（m） | Motor power（kw） | Drum diameter（φmm） | Roller diameter（φmm） | inclination（°） |
| DTC80/30/2×90S | 300 | 800 | 2 | 400 | 2×90 | 1000 | 89 | 20 |
| DTC80/30/2×132S | 300 | 800 | 2 | 400 | 2×132 | 1000 | 89 | 0~22 |
| DTC80/40×132S | 400 | 800 | 2 | 200 | 132 | 1000 | 89 | 20 |
| DTC80/40/2×160S | 400 | 800 | 2 | 600 | 2×160 | 1000 | 89 | 0~22 |
| DTC80/40/2×200S | 400 | 800 | 2.5 | 800 | 2×200 | 1250 | 108 | 16~25 |
| DTC100/50/2×250S | 500 | 1000 | 2 | 600 | 2×250 | 1000 | 108 | 20~22 |
| DTC100/50/2×280S | 500 | 1000 | 2.5 | 500 | 2×280 | 1250 | 108 | 26 |
| DTC100/63/2×315S | 630 | 1000 | 2.5 | 500 | 2×315 | 1250 | 108 | 26 |
| DTC120/80/2×315S | 800 | 1200 | 2.5 | 500 | 2×315 | 1400 | 133 | 22~26 |
| DTC120/70/2×450S | 700 | 1200 | 2.5 | 500 | 2×450 | 1400 | 133 | 22~26 |
| DTC120/100/3×400 | 1000 | 1200 | 3.15 | 600 | 2×400 | 1250 | 133 | 20~26 |
| DTC120/100/2×630S | 1000 | 1200 | 3.15 | 600 | 2×630 | 1250 | 133 | 20~26 |
