| Grab Technical Parameters | ||
| Volume | 0.4m³ | 0.6m³ |
| Cylinder diameter | 500mm | 600mm |
| Piston stroke | 575mm | 575mm |
| Number of grabs | 8片 | 8片 |
| Grab piece open outer diameter | ≥1965mm | ≥2500mm |
| Grip closed outer diameter | 1210mm | 1600mm |
| Compressed air working pressure | 0.5～0.7mpa | 0.5～0.7mpa |
| Dimensions（Closed state） | φ1210×2200（mm） | φ1600×2500（mm） |
| weight | 1900kg | 2500kg |
