| Drilling template Specifications | |||||
| diameter | 4.0-11.0 | ||||
| high | 2.5-6.0 | ||||
| Suspension method | sinking vehicle stability | ||||
| Hydraulic working pressure (MPa) | 16-24 | ||||
| Serial number | model | diameter | high | Chunking | structure |
| 1 | MYJ-4.05/4 | 4050 | 4000 | 9 | The specific design is based on the shaft diameter, shaft depth, ground pressure conditions, and concrete thickness. Channel steel can be changed into combined channel steel and artificial channel steel. The pouring port has window type and ring type. |
| 2 | MYJ-4.05/4 | 4550 | 4000 | 10 | |
| 3 | MYJ-4.05/4 | 5050 | 4000 | 11 | |
| 4 | MYJ-4.05/4 | 5550 | 4000 | 12 | |
| 5 | MYJ-4.05/4 | 6050 | 4000 | 13 | |
| 6 | MYJ-4.05/4 | 6550 | 4000 | 13 | |
| 7 | MYJ-4.05/4 | 7050 | 4000 | 13 | |
| 8 | MYJ-4.05/4 | 8060 | 4000 | 15 | |
| 9 | MYJ-4.05/4 | 9060 | 3600 | 17 | |
| 10 | MYJ-4.05/4 | 9460 | 3600 | 17 | |
| 11 | MYJ-4.05/4 | 9760 | 3600 | 19 | |
| 12 | MYJ-4.05/4 | 11360 | 3600 | 21 | |
