| Ordinal number |
Model | Maximum diameter of wire rope |
Single wire rope allows maximum static tension kN(t) | Main dimensions | Unit number | Bearing block bolthole Slze Ф*A*B |
weight | ||||||||||
| Trunnion d(H9/d9) |
journal d1(H9/f9) |
The wheel diameter D |
Outer diameter D1 |
Shaft Seat from |
Axial length L |
Center for high H |
The rope round |
Shaft sleeve |
shaft | Retaining ring |
Bearing | ||||||
| 1 | MZS2.1-0-1*0.5 | 23 | 50(5) | 90 | 70 | 500 | 565 | 280 | 430 | 90 | 1-1.1 | 2--1 | 3-1.1 | 4--1 | 5--1 | φ26*70*220 | 130 |
| 2 | MZS2.1-0-1*0.65 | 31 | 100(10) | 100 | 85 | 650 | 775 | 340 | 490 | 100 | 1-1.2 | 2--2 | 3-1.2 | 4--2 | 5--2 | φ26*70*250 | 230 |
| 3 | MZS2.1-0-1*0.8 | 40 | 160(16) | 120 | 100 | 800 | 960 | 400 | 560 | 110 | 1-1.3 | 2--5 | 3-1.3 | 4--3 | 5--3 | φ26*80*280 | 382 |
| 4 | MZS2.1-0-1*1.05 | 52 | 250(25) | 150 | 120 | 1050 | 1260 | 460 | 620 | 120 | 1-1.4 | 2--8 | 3-1.4 | 4--4 | 5--4 | φ26*80*300 | 670 |
| 5 | MZS2.1-0-1*1.25 | 60.5 | 400(40) | 180 | 140 | 1250 | 1495 | 520 | 680 | 140 | 1-1.5 | 2--10 | 3-1.5 | 4--5 | 5--5 | φ26*80*330 | 1088 |
| 6 | MZS2.1-0-1*0.8W | 29 | 100(10) | 120 | 85 | 800 | 920 | 400 | 550 | 100 | 1-1.6 | 2--4 | 3-1.6 | 4--3 | 5--2 | φ26*70*250 | 310 |
| 7 | MZS2.1-0-1*1.05W | 35.5 | 160(16) | 150 | 100 | 1050 | 1200 | 400 | 560 | 110 | 1-1.7 | 2--7 | 3-1.7 | 4--4 | 5--3 | φ26*80*280 | 500 |
