| Model | The diameter of the bottom circle of the rope groove D |
Rope grooveradius R | Maximum travelling distance S | Applicable steel wire rope diameter |
Allow the wire rope to break the tension |
| mm | k | ||||
| TDG 600/9/300 | 600 | 9 | 300 | 14-16 | 160 |
| TDG 800/11/700 | 800 | 11 | 700 | ＞16-20 | 252 |
| TDG 1000/13.5/800 | 1000 | 13.5 | 800 | ＞20-24.5 | 382 |
| TDG 1400/16/740 | 1400 | 16 | 740 | ＞24.5-30 | 597 |
| TDG 1400/16/1350 | 1350 | ||||
