| Model | Design load(t) | Dimensions(L×B)(mm) | Hook opening diameter | Thrust bearing model | Hook device weight(kg) | Connected wire rope diameter | Static load test safety factor | Suitable bucket specifications(m³） | |
| Hook type | Bottom groove type | ||||||||
| G5Ⅰ | 5 | 1290×460 | 90 | 51311 | 76.5 | 26-28 | 13 | 2.0 | 1.5 |
| G7Ⅰ | 7 | 1495×515 | 100 | 51313 | 106 | 31-35 | 13 | 3.0 | 2.0 |
| G7 | 7 | 1538×515 | 100 | 51313 | 130 | 31-35 | 13 | 3.0 | 2.0 |
| G9Ⅰ | 9 | 1660×590 | 120 | 51413 | 166 | 37-40 | 13 | 4.0 | 3.0 |
| G9 | 9 | 1750×590 | 120 | 51413 | 193 | 37-40 | 13 | 4.0 | 3.0 |
| G11Ⅰ | 11 | 1725×618 | 120 | 51315 | 198 | 40-43 | 13 | 5.0 | 4.0 |
| G11 | 11 | 1850×618 | 120 | 51315 | 231 | 40-43 | 13 | 5.0 | 4.0 |
| G13 | 13 | 1952×680 | 130 | 51316 | 312 | 44-16 | 13 | 6.0 | 5.0 |
| G15 | 15 | 2070×680 | 130 | 51317 | 334 | 48-52 | 13 | 7.0 | 5.0 |
| G18 | 18 | 2070×680 | 130 | 51317 | 350 | 48-50 | 13 | 8.0 | 5.0 |
