| Bucket form | Model | Volume (m³) | Drum body diameter(mm) | Drum diameter (mm) | Drum height ( mm) | Full height of drum (mm) | Drum beam diameter(mm) | Weight ( kg) |
| Hook type | MZS5.1-0 | 0.5 | φ825 | φ725 | 1100 | 1730 | φ40 | 194 |
| MZS5.2-0 | 1 | φ1150 | φ1000 | 1150 | 2005 | φ55 | 348 | |
| MZS5.3-0 | 1.5 | φ1280 | φ1150 | 1280 | 2270 | φ65 | 478 | |
| MZS5.4-0 | 2 | φ1450 | φ1320 | 1300 | 2430 | φ70 | 601 | |
| Bottom groove type | MZS5.5-0 | 2 | φ1450 | φ1320 | 1350 | 2480 | φ70 | 728 |
| MZS5.6-0 | 3 | φ1650 | φ1450 | 1650 | 2890 | φ80 | 1049 | |
| MZS5.7-0 | 4 | φ1850 | φ1630 | 1700 | 3080 | φ90 | 1530 | |
| MZS5.7-0 | 5 | φ1850 | φ1630 | 2100 | 3480 | φ90 | 1690 |
