| JK Fast winch parameters | ||||||||
| Basic parameter model | Rated tensile force | Average rope speed | Rope capacity | Wire rope diameter | Motor Model | Motor power | Reducer | Machine weight |
| JK0.5 | 5 | 22 | 110 | φ7.5 | Y100L2-4 | 3 | ZQ250 | 200 |
| JK1 | 10 | 22 | 80 | φ9.3 | Y112M-4 | 4 | ZQ250 | 300 |
| JK1.6 | 16 | 24 | 115 | φ12.5 | Y132S-4 | 5.5 | ZQ350 | 500 |
| JK2 | 20 | 24 | 110 | φ12.5 | Y132M-4 | 7.5 | ZQS350 | 550 |
| JK3.2 | 32 | 30 | 250 | φ15.5 | YZR180L-6 | 15 | ZQS550 | 1150 |
| JK5 | 50 | 30 | 240 | φ21.5 | YZR225M-6 | 30 | ZQS650 | 2500 |
| JK8 | 80 | 30 | 210 | φ26 | YZR280S-8 | 45 | ZQS750 | 3500 |
| JK10 | 100 | 30 | 300 | φ30 | YZR315S-8 | 55 | ZQS850 | 5100 |
