| Model | Nominal diameter Dt(m) | Rope groove radius R(mm) | Diameter of wire rope (mm) | Two bearing center distance (mm) | Height of bearing center(mm) |
| TLG-800/16 | 0.8 | 15 | 16 | 350 | 100 |
| TLG/1000/20 | 1 | 15 | 20 | 400 | 125 |
| TLG-1200/20 | 1.2 | 15 | 20 | 500 | 125 |
| TLG-1600/24 | 1.6 | 15 | 24 | 550 | 180 |
| TLG-2000/26 | 2 | 18 | 26 | 800 | 220 |
| TLG-2500/30 | 2.5 | 21 | 30 | 800 | 220 |
| TLG-3000/40 | 3 | 24 | 36-42 | 950 | 330 |
